Home > Special purposs vehicleForkliftXCMG FD18T Forklift
One-piece designed of suspension frame.
New water tank & cooling system.
Larger operation space.Optimized steering wheel, operating handle and pedals.
High-efficency hydraulic system, lower fuel comsumption.
Enhanced wide view mast improves the work efficency and operating safety.
Model | FD18T | |
Power Type | Diesel | |
Rated Load Capacity | Q(kg) | 1800 |
Load Centre | C(mm) | 500 |
Rated Lift Height | H3(mm) | 3000 |
Free Lift Height | H2(mm) | 100 |
Fork Size (L×W×T) | mm | 1070×120×40 |
Mast Tilt Angle (F/R, α°/β°) | deg | 6°/12° |
Fork Overhang (Wheel Center to Fork Face) | X1(mm) | 409 |
Rear Overhang | X2(mm) | 490 |
Ground Clearance (Bottom of Mast) | H7(mm) | 110 |
Length to Face of Fork (Without Fork) | L1(mm) | 2290 |
Overall Width | B1(mm) | 1090 |
Mast Lowered Height | H1(mm) | 2025 |
Mast Extended Height (With Backrest) | H4(mm) | 4055 |
Overhead Guard Height | H5(mm) | 2180 |
Turning Radius (Outside) | Wa(mm) | 2060 |
Tyre (Front x 2) | mm | 6.50-10-10PR |
Tyre (Rear x 2) | mm | 5.00-8-10PR |
Total Weight | kg | 2890 |
Battery | V/Ah | 12/90 |
