Home > Special purposs vehicleForklift XCMG FD100 Forklift
Model | FD100 | |
Power Type | Diesel | |
Rated Load Capacity | Q(kg) | 6000 |
Load Centre | C(mm) | 500 |
Rated Lift Height | H3(mm) | 3000 |
Free Lift Height | H2(mm) | 84 |
Fork Size (L×W×T) | mm | 1070×150×50 |
Mast Tilt Angle (F/R, α°/β°) | deg | 6°/12° |
Fork Overhang (Wheel Center to Fork Face) | X1(mm) | 578 |
Rear Overhang | X2(mm) | 614 |
Ground Clearance (Bottom of Mast) | H7(mm) | 175 |
Length to Face of Fork (Without Fork) | L1(mm) | 3125 |
Overall Width | B1(mm) | 1485 |
Mast Lowered Height | H1(mm) | 2260 |
Mast Extended Height (With Backrest) | H4(mm) | 4266 |
Overhead Guard Height | H5(mm) | 2240 |
Turning Radius (Outside) | Wa(mm) | 2830 |
Travel Speed (No Load) | km/h | 22 |
Lifting Speed (Full Load) | mm/sec | 430 |
Tyre (Front x 2) | mm | 300-15-18PR |
Tyre (Rear x 2) | mm | 7.00-12-12PR |
Total Weight | kg | 8640 |
Battery | V/Ah | 24/80 |
