Model | XZ2400 | |
Engine | CUMMINS | |
Rated power | kW | 528 (2X264)/2200 |
Max.pullback/thrusting | kN | 2860/2860 |
Spindle torque(max) | N.m | 90000 |
Spindle speed | r/min | 0～95 |
Spindle travelling speed | m/min | 0～25 |
Backreaming diameter | mm | - |
Tubing length(single) | m | 9.6 |
Tubing diameter | mm | φ140 |
Entry angle | ° | 10～18 |
Mud flow rate(max) | L/min | - |
Mud pressure (max) | bar | - |
Overall weight | kg | ≤48000 |
DIMENSION (LxWxH) | mm | 17500 X3200X3400 |
