Item | Unit | Specification |
Dimensions | ||
Overall length | mm | 13770 |
Overall width | mm | 2800 |
Overall height | mm | 3570 |
Wheel base | mm | 1470+4105+1350 |
Wheel track | mm | 2304/2304/2075/2075 |
Weight | ||
Total weight in travel | Kg | 42000 |
Axle load | Kg | Front 16000 rear 26000 |
Power | ||
Engine model | D10.38A-40/SC10E380.1Q4/WP10.375E41 | |
Engine rated power | kw/(r/min) | 276/2200 279/2200 276/2200 |
Engine rated torque | N.m/(r/min) | 1500/（1100～1600） 1500/1300 1480/（1200～1600） |
Travel | ||
Travelling | ||
Max. travel speed | km/h | 80 |
Min. stable travel speed | km/h | - |
Turning | ||
Min. turning diameter | m | 24 |
Min. turning diameter(boom head) | m | 28.158 |
Max. grade ability | ％ | 40 |
Min. ground clearance | mm | 327 |
Approach angle | ° | 17 |
Departure angle | ° | 11 |
Braking distance | m | ≤10 |
Fuel consumption for 100km | L | 42 |
Lifting performance | ||
Max. total rated lifting capacity | t | 50 |
Min. rated working radius | m | 3 |
Base boom Max. load moment | kN·m | 1822 |
Turning radius at turntable tail | mm | 3482 |
Outrigger | ||
Longitudinal distance span | m | 5.91 |
Lateral distance span | m | 6.9(4.7) |
Max. lifting height | ||
Base boom | m | 11.5 |
Fully extended boom | m | 42.7 |
Fully extended boom＋jib | m | 57.7 |
Boom length | ||
Base boom | m | 11.3 |
Fully extended boom | m | - |
Fully extended boom＋jib | m | - |
Fully extended boom＋jib+ extension | m | -- |
Working speed | ||
Max. swing speed | r/min | 2 |
Lifting speed | ||
Main winch | s | Fully-load 85 no-load130 |
Vice winch | s | Fully-load 85 no-load130 |
Boom full extension time | ||
extension | s | 85 |
contraction | s | - |
Boom elevating time | ||
Lifting | s | 40 |
Dropping | s | - |
Outrigger full extension time | ||
Horizontal | ||
Stretching | s | 30 |
Retracting | s | 20 |
Vertical | ||
Stretching | s | - |
Retracting | s | - |
