1. Equipped with DEUTZ water-cooled engine, the power reserve is large, the fuel consumption is low, the noise is small, and it meets the national III emission standard.
2. The closed hydraulic drive system consisting of a variable pump and a two-variable motor realizes full drive of the front and rear wheels, ensuring that the roller has good driving performance and climbing ability.
3. Four-speed stepless speed change, to ensure that the work at the most appropriate speed under different working conditions.
Specification
Operating weight | kg | 30000 |
Load applied on front drum | kg | 18000 |
Engine rated power | kW | 179 |
Engine rated speed | r/min | 2200 |
Static linear load | N/cm | 845 |
Nominal amplitude (high/low) | mm | 1.0/2.0 |
Vibration frequency(high/low) | Hz | 33/27 |
Exiting force (high/low) | kN | 390/520 |
Speed(Ⅰ/Ⅱ/Ⅲ/IV) | km/h | 0-3.8/0-5.6/0-5.6/0-10.6 |
Theoretical gradeability | % | 40 |
Min. outer turning radius | mm | 7020 |
Swing angle | ° | ±10 |
Steering angle | ° | ±33 |
Dimension(L*W*H) | mm | 6057×2520×3330 |
Wheelbase | mm | 3510 |
