Item	Unit	Specification
Weight
Operating weight	kg	15000
Counter weight	kg	10550
Water weight	kg	650
Max. working weight	kg	26300
Working performance
Compaction width	mm	2750
Overlap of front and rear wheels	%	45
Ground pressure	kPa	200-420
Min. ground clearance	mm	300
Travelling performance
Speed range Forward I	km/h	0-8
Forward II	km/h	0-20
Forward III	km/h	-
Backward I	km/h	0-8
Backward II	km/h	0-20
Wheel base	mm	3840
Wheel track	mm	490
Theoretical gradeability	%	20%
Min. turning radius	mm	7820
Engine
Model		SC8D156.2G2B1
Rated speed	r/min	1800
Rated power	Kw	132
The fuel consumption	g/Kw·h	221
Max. torque	N.m	765
Displacement	L	8.27
Dimensions
Overall dimensions(L×W×H)	mm	5060×2851×3395
