Home > Road machineryRoad roller XCMG XMR303 Light-weight Roller
Main parameter:
Operating weight :3.1 tons ,
Vibration frequency :60 Hz,
Drum width:1200 mm,
Detailed configuration
F2L2011 engine
Hydraulic double drive
Single vibratory drums for XMR303, Double vibratory drums for XMR303S
Advantages
Adopt good brand engine , pump ,vibratory bearing .Great working performance .
Easy for compaction even on road side .High working efficiency .
Equip large capacity water tanks.
XMR303 light double drum vibratory roller is suitable for surface compaction of compaction works such as asphalt engineering and cement engineering and compaction of curbs. It is also suitable for compaction of base and base layers, sand and gravel materials.
Item | Unit | XMR303 |
Operating weight | kg | 3100 |
Static linear load(front/rear) | N/cm | 129/129 |
Travel Speed | km/h | 0-9.5 |
Theoretical agreeability | % | 30 |
Min. turning radius(Inner/Outer) | mm | 2890/4090 |
Min ground clearance | mm | 310 |
Steering angle | ± ° | 30 |
Swing angle | ±° | 10 |
Vibration frequency | Hz | 60 |
Vibrating system-max.pressure | Mpa | 20 |
Steering system-max.rressure | Mpa | 14 |
Nominal amplitude | mm | 0.46 |
Exiting force | kN | 32 |
Compacting width | mm | 1200 |
Overall dimensions(L×W×H) | mm | 2675×1318×2680 |
