Weichai turbocharged electronic injection diesel engine system, low emissions, low noise, low fuel consumption, fulfilling the requirements of Chinese Stage III emission standard. Three level power regulation control technology, allowing the machine working in the best fuel consumption area, more energy efficient.
Sprinkler system: automatic/manual control mode, user-friendly control, high spraying precision. Sprinkling water pump has self-priming function, can be seamless connected to all kinds of water wheel wagon.
Milling system: the grain size of milling material can be adjusted according to the rotor speed and operating speed, so as to ensure the uniformity of material granularity, meeting the requirements of different grading.
Front axle drive mode, propelling speed and operating speed is stepless variable, convenient for operation.
Milling rotor end door can be opened to large angle by electro-hydraulic control, cutting tools are fast and convenient to replace.
Optional rear wheel drive system adapt to complex conditions such as certain degree of muddy, slippery roads.
Model | Unit | XLZ2103 | |
Milling width | mm | 2100 | |
Maximum milling depth | mm | 400 | |
Engine | Manufacturer | Weichai engine | |
Engine model | WP12.460N | ||
Rated power /speed | Kw/rpm | 338/1900 | |
Performance parameters | Operating speed | m/min | 0~40 |
Travel speed | Km/h | 0~18.5 | |
Gradeability | % | ≥20%(11.3°) | |
Ground clearance | mm | 400 | |
Operating weight | Kg | 23800 | |
