Home > Earth moving machineryTelescopic HandlerXCMG XC6-3507K Telescopic Handler
Description | Unit | Parameter value |
Engine Power | kW | 70 |
Overall weight (±5%) | kg | 7850 |
Overall dimensions (±2%) | mm | 5065×2250×2470 |
Maximum traveling speed | m/h | 30 |
Turning radius | mm | 3880 |
Maximum effective load | kg | 3500 |
Effective load at maximum extending length | kg | 1250 |
Maximum lifting height (±100) | mm | 7150 |
Maximum forward reach (±100) | mm | 3600 |
Center distance of load | mm | 600 |
Luffing angle (±1º) | ° | -3~65 |
Inclination of fork carrier (forward (±1.5)/backward (±1)) | ° | 90/17.5 |
Maximum traction force | KN | 70 |
Wheelbase (±2%) | mm | 2985 |
Wheeltread (±2%) | mm | 1840 |
