Description	Unit	Parameter value
Overall dimensions (L´W´H)	mm	9350×2480×2970


Fuel		Diesel
Engine emission standard		China IV
Displacement/Rated power	L/kW	6.87/151
Steering type		Steering wheel
Axle number		2
Wheelbase	mm	4800
Steel spring number (front/rear)		11/9+8
Tire		9.00R20
Track (front /rear)	mm	2064/1860
Tire number (spare tire excluded)		6
Permitted number in the driver cab		2
Approach/departure angle	°	10/19
Front/rear overhang	mm	1430/1860
Max. driving speed	km/h	90
Min. ground clearance	mm	256
Max. grade-ability	%	40
Oil consumption per 100km	L	22
Chassis	Model	ZZ1167M481GD1/M7M7
	Type	Category II
	Manufacturer	Sinotruk
Engine	Model	MC07.28-40
Engine	Manufacturer	Sinotruk
Volume of fuel tank	L	400
Number of fuel tank		1
Min. turning diameter	m	16
