XGC260 is the new generation crawler crane which is successfully developed by XCMG after QUY260. Built on multiple originally developed technologies, this "star product" will guide the technical innovation orientation in this industry, the overall crane technology reaches the world-leading level.
1. Super-powerful lifting performance
Combining the technology of integrated large chassis design with low center of gravity with optimized lightweight boom design, with advanced 93m boom + 66m tower jib XGC260 has better stability, stronger lifting capacity, wider operation range and higher lifting height.
The max. lifting capacity of TBM working condition is 166.2t, one XGC260 can realize the turning and installation of TBM equipment within diameter of 8m.
2. The lowest cost in operation and transportation
With optimized boom section combination, one boom structure set will realize two working conditions: TBM jib, wind power jib working condition, which greatly improve Crane universality and interchangeability of components, and reduce transport components.
3. Unique appearance and used-friendly design
The bionic design of the cab makes operation more convenient and comfortable with more novel fashion appearance and simulation of human body interior software simulation.
The crane reflects excellent overall quality by interacting cab with streamline turntable, delicate counterweight and “X" type coating.
Item | Unit | Specification |
Lifting performance | ||
Max. total rated lifting capacity | t | 260 |
Fixed jib Max. lifting capacity | t | 105 |
Luffing jib Max. lifting capacity | t | 95 |
Max. load moment | t.m | 1450 |
Tower jib Max. lifting capacity | t | 95 |
Single block Max. lifting capacity | t | 28 |
Special jib Max. lifting capacity | t | 150.2 |
Dimensions | ||
Main boom length | m | 24~93 |
Main boom luffing angle | ° | -3~85 |
Fixed jib length | m | 9~36 |
Tower jib length | m | 24~66 |
Max. dimension of single unit(basic machine)in travel configuration(Lx W x H) | m | 13.2×3.0×3.2 |
Fixed jib installation angle | ° | 10、30 |
Special jib length | m | 9~12 |
Working speed | ||
Winch Max. single line speed | m/min | 108 |
Boom luffing gear Max. single line speed | m/min | 2×42.5 |
Vice jib luffing gear Max. single line speed | m/min | 135 |
Max. slewing speed | r/min | 1.1 |
Max. travel speed | km/h | 1.2 |
Grade ability | % | 30 |
Mean ground pressure | MPa | 0.116 |
Tower jib luffing gear Max. single line speed | m/min | 135 |
Lifting device luffing gear Max. single line speed | m/min | - |
Power | ||
Engine model | WP10 | |
Engine rated power | kW | 242 |
Discharge | Ⅲ | |
Weight | ||
Total weight | t | 239(main lifting hook,24m boom) |
Max. single unit weight for transportation | t | 43(Disassembly can be less than 37 tons) |
