Description	Unit	Parameter value
Max. drilling diameter	mm	3000
Max. drilling depth	m	120
Allowable luffing scope (from center of drill rod to slewing center)	mm	4700~5000
Drilling rig dimension in working condition (L × W × H)	mm	10750×5500×31060
Drilling rig dimension in transport condition (L × W × H)	mm	10750×5500×31060
Weight of overall unit (standard configuration, excluding drilling tool)	t	158
Engine	Model		CUMMINS QSX15-C600
	Rated power/speed		kW	447/(2100r/min)
Max. working pressure of hydraulic system	Mpa	35
Rotary drive	Max. torque		kN •m	460
	Rotational speed		r/min	5.5~20
Crowd cylinder	Max. Pushing force		kN	300
	Max. Pulling force		kN	400
	Max.stroke		mm	6000
Crowd winch	Max. Pushing force		kN	500
	Max. Pulling force		kN	500
	Max.stroke		mm	16000
Main winch	Max.pulling force		kN	520
	Max. single-rope speed		m/min	60
	Diameter of the steel wire rope		mm	42
Drilling mast	Left/right inclination of mast		°	3/3

				5/5
	Front/back inclination of mast		°	5/15
Rotary table slewing angle	°	360
Crawler	Width of crawler plate		mm	1000
	External width of crawler (min.-max.)		mm	4050~5500
	Center distance between two longitudinal wheels of crawler		mm	6050
	Average ground pressure		kPa	121.3
