During the development process of XGC16000, multiple key technologies has been inherited or overcome, laying firm technical foundation for further development of larger tonnage products. It breaks the super large crawler crane monopoly processed by foreign manufactures in china’s large constriction equipment market, and accelerates the technical updating of our engineering crane industry.
Performance Characteristics:
Heavy boom length in standard working condition is 96m, light boom length 114m, and superlift tower jib length 108m.
Engine water radiator and intercooler have independent intelligent control system, can respectively control different strength of heat radiation according to different environment，reduced engine power loss, with energy-saving and high work efficiency.
Split-type overall structure, small transport size, except for lower basic machine, transport width 3.538m， other parts transport width smaller than 3.5m.
Adjustable built-in boom transport device, winch and pulley stored in the winch for transport, reduced transport size, avoided disassembly and saved assembly time.
Item | Unit | Specification |
Lifting performance | ||
Max. total rated lifting capacity | t | 1250 |
Fixed jib Max. lifting capacity | t | - |
Luffing jib Max. lifting capacity | t | 477 |
Max. load moment | t.m | 15510 |
Tower jib Max. lifting capacity | t | 477 |
Single block Max. lifting capacity | t | 45 |
Special jib Max. lifting capacity | t | 629 |
Dimensions | ||
Main boom length | m | 30～120(H)/48～150(L) |
Main boom luffing angle | ° | -3～85° |
Fixed jib length | m | - |
Tower jib length | m | 30～108 |
Max. dimension of single unit(basic machine)in travel configuration(Lx W x H) | m | 15.5×3.4×3.12 |
Fixed jib installation angle | ° | - |
Special jib length | m | 18 |
Working speed | ||
Winch Max. single line speed | m/min | 130 |
Boom luffing gear Max. single line speed | m/min | 53×2 |
Vice jib luffing gear Max. single line speed | m/min | - |
Max. slewing speed | r/min | 0.9 |
Max. travel speed | km/h | 0.8 |
Grade ability | % | 30% |
Mean ground pressure | MPa | 0.156 |
Tower jib luffing gear Max. single line speed | m/min | 125 |
Lifting device luffing gear Max. single line speed | m/min | 130 |
Power | ||
Engine model | QSK23 | |
Engine rated power | kW | 641 |
Discharge | EURⅡ | |
Weight | ||
Total weight | t | |
Max. single unit weight for transportation | t | 59 |
