Home > Earth moving machineryExcavatorXCMG XE700D Crawler Excavator
More energy-conservation and environmental protection
By adopting the international famous brand Cummins engine. It meets TIER 3 emission standard, with advantages of strong power, low noise, low fuel consumption and low emission, and is able to meet demands of various construction con-ditions.
It adopts high-pressure fuel injection system, and may realize electric control of the whole course of fuel injection through controlling fuel supply actuator and timing actuator with ECM, so as to exactly control fuel injection amount and fuel injection time, thus reducing fuel consumption and enhancing engine efficiency.
More reliable and durable
XE700D adopts Donaldson STG series heavy grayscale air filter imported with original packaging from the USA, with filtering efficiency reaching 99.99%，and adapts to working conditions with much dust and humidity.
XE700D is set with three-stage fuel filtering system (one stage for coarse filtering and two stages for fine filtering) to effectively filter sundries in fuel, thus making sure the engine can run continuously and reliably with high load for a long time under severe working conditions.
Item | Unit | Specifications（XE700D） | |
Main performance | Travel speed(H/L) | km/h | 4.2/3.0 |
Grade ability | % | 35 | |
Rotary speed | r/min | 7 | |
Ground pressure | K Pa | 101.4 | |
Bucket digging force | kn | 363 | |
Arm digging force | kn | 300 | |
Travel traction force | kn | 450 | |
Hydraulic system | Main pump | - | 2 |
Rated flow of main pump | L/min | 2*450 | |
Pressure of prime valve | M Pa | 31.4/34.3 | |
Pressure of travel system | M Pa | 34.3 | |
Pressure of swing system | M Pa | 28.5 | |
Pressure of pilot system | M Pa | 3.9 | |
Oil Capacity | Fuel tank capacity | L | 950 |
Hydraulic tank capacity | L | 500 | |
Engine oil capacity | L | 48 | |
