The excavator with short-tail design can apply to the narrow work conditions. The engine powertrain is featured with stable torqueoutput, low fuel consumption and low noise. The load hydraulic sensitive system allows for improved maneuverability of compoundactions, faster response speed, accurate control and small impact.
Strengthen the local area of boom and arm bearing high stress, and meanwhile adjust the structure, disperse stress and improve theservice life; standard new-type bucket and reduced bucket depth make unloading quicker and faster.It is easy to achieve fine wo rksuch as flat land.
It is widely used in small earth and stone works, municipal construction, road repair, concrete crushing, buried cables, farmland water conservancy construction, garden cultivation and river channel dredging.
Item | Unit | Specifications（XE55DA） |
Operating weight(without dozer blade) | Kg | 5750 |
Bucket capacity | m³ | 0.21 |
Engine Model | / | Kubota V2607 |
No. of cylinders | / | 4 |
Rated power/speed | kw/rpm | 35/2200 |
Maximum torque/speed | N.m | 171.5/1300 |
Displacement | L | 2.615 |
Travel speed(H/L) | km/h | 4.2/2.2 |
Rotating speed | r/min | 10 |
Grade ability | ° | ≤35 |
Ground pressure | K Pa | 31 |
Bucket digging force | KN | 48.3 |
Arm digging force | KN | 32.5 |
Maximum tractive force | KN | 50.5 |
Main pump | / | / |
Rated flow of main pump | L/min | 150 |
Main safety valve pressure | M Pa | 24.5 |
Travel system pressure | M Pa | 24 |
Swing system pressure | M Pa | 23 |
Pilot system pressure | M Pa | 3.5 |
Fuel tank capacity | L | 110 |
Hydraulic tank capacity | L | 85 |
Engine oil capacity | L | 9 |
Overall length | mm | 5860 |
Overall width | mm | 1920 |
Overall height | mm | 2585 |
Width of platform | mm | 1780 |
Track length | mm | 2540 |
