Main parameters:

Bucket capacity:1CBM (standard)

Operating weight:21900kg

Max digging height:9620mm

Item		Unit	Specifications（XE215D）
Operating weight		kg	21900
Bucket capacity		m³	0.8～1.3
Engine	Model	Engine	QSB7
	Direct injection	---	√
	Four strokes	---	√
	Water cooling	---	√
	Turbo-charging	---	√
	Air to air inter cooler	---	√
	No. of cylinders	---	6
	Output power	kW/ r/min	135/2050
	torque/speed	N.m	740/1250
	Displacement	L	6.7
	Travel speed（H/L)	km/h	5.4/3.1
Main performance	Grade ability	%	70
	Rotary speed	r/min	11.8
	Ground pressure	K Pa	47.2
	Bucket digging force	KN	149
	Arm digging force	KN	111
Hydraulic system	Main pump	--	K7V125
	Rated flow of main pump	L/min	2×225
	Main safety valve pressure	M Pa	34.3/37
	Pressure of pilot system	M Pa	3.9
Oil Capacity	Fuel tank capacity	L	400
	Hydraulic tank capacity	L	220
	Engine oil capacity	L	19.5
	Overall length	mm	9625
Appearance size	Overall width	mm	2990
	Overall height	mm	3100
	Width of platform	mm	2830
	Length of crawler	mm	4255
	Overall width of chassis	mm	2990
	Width of crawler	mm	600
	Wheel base of crawler	mm	3462
	Crawler gauge	mm	2390
	Clearance under counterweight	mm	1050
	Min. ground clearance	mm	476
	Min. rear-end swing radius	mm	2890
	Max. digging height	mm	9620
Working scope	Max. dumping height	mm	6780
	Max. digging depth	mm	6680
	Max. digging depth at the range of level 8 feet	mm	6500
	Max. vertical wall digging depth	mm	5715
	Max. digging reach	mm	9940
	Min. swing radius	mm	3530
Worker Standard	Length of boom	mm	5680
	Length of arm	mm	2910
	Bucket capacity	m³	1
