Home > Concrete machineryTruck mounted concrete pump XCMG HB67K Truck Mounted Concrete Pump
Similar Product
Select the products
Item | Parameters | Unit | |
Outline dimension | 15780×2500×4000 | mm | |
Overall weight | 54000 | kg | |
Chassis | Model | Actros5046 | |
Manufacturer | Daimer | ||
Max. speed | 85 | km/h | |
Max. grade-ability | 51.4 | % | |
Wheelbase | 2020+5180+1350+1450 | ||
Tire | --- | ||
Engine | Model | OM501LA.V6 | |
Max. power | 335 | kW | |
Max. torque | 2200/1080 | N·m/(r/min) | |
Displacement | 11.949 | L | |
Emission standard | Eruo Ⅴ | ||
Pumping system | Theoretical output | 170 | m³/h |
Concrete pumping pressure | 8 | MPa | |
Theoretical pumping times | 21~23 | Time/min | |
Delivery cylinder diameter ×stroke | φ260×2200 | mm | |
Max. diameter of pumping concrete | ≤40 | mm | |
Filling height | 1570 | mm | |
Concrete slump range | 8~23 | cm | |
Placing boom | Reach height | 66.1 | m |
Reach depth | 48.6 | m | |
Slewingradius | 60.9 | m | |
Slewing angle | ±270 | ° | |
Unfolding angle of the 1st section | 90 | ° | |
Unfolding angle of the 2nd section | 180 | ° | |
Unfolding angle of the 3rd section | 180 | ° | |
Unfolding angle of the 4th section | 230 | ° |
