2016-2-29
Last
week we exported new one XCMG paver RP452L.
The paver specification as follow:
|
Theoretical Productivity |
t/h |
240 |
|
Max. paving width |
m |
4.5 |
|
Max. paving thickness |
mm |
150 |
|
Paving speed |
m/min |
13 |
|
Smoothness |
mm |
3 |
|
Dense Degree |
% |
≥80 |
|
Dense irregularity |
% |
＜5 |
|
Travelling specification |
|
|
|
Max. travelling speed |
km/h |
13 |
|
Driving type |
|
Wheel |
|
Grade ability |
% |
20 |
|
Min. turning diameter (wheel) |
m |
16 |
|
Driving brake |
|
Hydrostatic + multiple disk brake |
|
parking brake |
|
Wet multiple disk brake |
|
Crawler tension (caterpillar) |
|
/ |
|
Braking distance (wheel) |
m |
4.7 |
|
Tire size (wheel) |
|
974 |
|
Material transporting specification |
|
|
|
Structural style |
|
Transporting linkage |
|
Drive method |
|
Bridge type hydraulic drive |
|
Scraper conveyor speed |
m/min |
0～30 |
|
Spiral feeding speed |
r/min |
0～73 |
|
Screw diameter |
mm |
360 |
|
Lubrication method |
|
Manual lubrication |
|
Screed specification |
|
|
|
Assembled form |
|
Hydraulic extension |
|
Basic width |
m |
2 |
|
Compact device |
|
|
|
Screed heating |
|
Gas heating |
|
Tamper trip |
mm |
/ |
|
Tamper revolution |
r/min |
/ |
|
Vibrational frequency |
Hz |
6～42 |
|
Arciform range |
% |
0～+3 |
|
Weight specification |
|
|
|
Gross weight(including screed) |
kg |
10900 |
|
Max. gross weight(working condition) |
kg |
11500 |
|
Structure specification |
|
|
|
Dimensions(L×W×H) |
mm |
5690×2070×3590 |
|
Grounding area (caterpillar) |
mm |
/ |
|
Hopper capacity |
t |
12 |
|
Hopper width |
mm |
3000 |
|
Hopper length |
mm |
1740 |
|
Engine |
|
|
|
Model |
|
Yuchai YC4D95Z-T21 |
|
Rated power/speed |
kW/r/min |
70/2200 |
|
Emission |
|
non-road, National Ⅱ |
|
Fuel tank capacity |
L |
130 |
