2010-6-10

Recently our company exported Nigeria with xcmg road roller XS120PD and GR180 grader.

The roller padfoot drum has two type, one is exchanged can be dismountable, another is welded as a whole part. The grader has option attachment parts to choose, like ripper or blade or heater.

The specification for both machineries as follow:

XCMG Single Drum Vibratory Road Roller XS120(PD)

With the type of hydrodynamic-mechanical drive, the compactor is steered by front axle, and driven by front and rear axles. The output power of the engine passes the transmission and main reducer to drive axle and full hydraulic steering system.

Operation mass(including operator+50%fuel):12400 ( XS120PD 13500 )

Front drum allotment mass:7400 ( XS120PD  8100 )

Rear wheel allotment mass:5000 ( XS120PD 5400 )

Static liner load(N/cm)     355

Vib.frequency(HZ)   High amp.         30

                                Low amp.          35

Gr180

Dimension(LxWxH) :8900×2625×3470mm

Operating weight(Standard):15400kg

Moldboard width X height：3965×610mm

Maximum lift above ground ：450mm

Maximum depth of cutting：500mm
