2013-8-26

Recently we exported one unit QY20B.5 for Myanmar tender project.

The specification as follow:

Overall dimention: 12400*2500*3300mm

Total weight in travel: 26020kg

Front axle load: 6900kg

Rear axle load: 19120kg

Max. travel speed: 75km/h

Min. turning diameter: 20m

Min. ground clearance: 270mm

Max. rated total lifting capacity: 20t

Min. rated working radius: 3000mm

Turning radius at turntable tail: 3.385m

Max. lifting torque: 860kN.m

Base boom: 10.06m

Fully extended boom: 32.76m

Fully extended boom+jib: 42.12m

Longitudinal outrigger span: 4.97m

Lateral outrigger span: 5.4m
