2012-3-5
Beibang machinery new order with XZ180
Horizontal directional driller, XCMG machinery has good reputation in South
Asia countries these years. The specification as follow:
Items | Unit | Parameters | ||
Engine | Make |
| 6BT5.9-C130 | |
Rated power | kW/ rpm | 97/2200 | ||
Push/pull force | Type |
| Dual-Motor drive gear transmission | |
Max. torque of power head | N.m | 6000 | ||
Power head rotary speed | r/min | 0~140 | ||
Diameter | mm | φ60 | ||
Length (single) | m | 3 | ||
Drill mounting | Type |
| Self-propelled rubber crawler | |
Flow | L/min | 250 | ||
Dimension | mm | 6400x2270x2340 | ||
Weight(incl. a box of drill stems ) | t | 10 | ||
