Beibang machinery exported new Multi Functional Paver RP756 this week. About the paver, High capability of material distribution, large spiral pitch 360mmΦ420 large diameter distribution blade, 28BH reinforced drive chain, and the drive ability is 25% larger than similar products.

Specification as follow:

Basic paving width: 3m

Max. paving width: 7.5m

Max. paving thickness: 350mm

Paving speed: 0～18m/min

Travel speed: 0～3.0km/h

Theoretical Productivity: 600t/h

Hopper Capacity: 14t

Gradeability: 20%

Pavement evenness: 3mm/3m

Transverse levelling accuracy: ±0.03%

Centre crown ratio: -1～3%

Engine model: D6114ZG1B

Engine power: 140kw

Engine speed: 2300r/min

Fuel tank capacity: 270L

Machine weight: 19.9～24.6t

Dimension: 6700×3000×3850mm

Vibration frequency (optional): 0～50Hz

Screed heating: Gas heating

Auger and conveyor control: Automatic Control by Ultrasonic Sensors

Automatic levelling control: Simulation control
