2012-9-17

The SD16L Extra-Swamp Bulldozer was developed to meet the requirements for operation in wetlands. The SD16L is equipped with a hydraulic drive system with hydraulic control technology and an advanced structure, providing reliable performance and convenient and flexible operation, making the SD16L the ideal construction machine for muddy or wet environments.

D16L Specification

Dimension(Ripper not included): 5262×4150×3074mm

Operating weight (Ripper not included): 17.5t

Rated power: 120/1850kW/rpm

Blade type: Straight tilt blade-

Blade width: 4150×960mm

Dozing capacity: 3.8m3

Max drop below ground of blade: 485mm

Lift height of blade: 1005mm

Ripper type: Three-shank ripper-

Number of carriers (each side): 2-

Number of track rollers (each side): 7-

Number of track shoes (each side): 42-

Width of track shoe: 1  3/19mm

Track gauge: 2300mm

Ground length and ground pressure: 2935-0.027mm/MPa

Pitch: 203.2mm
