2012-1-10
There has been XZ400 horizontal directional drilling exported to South Asian countries this month. The past two years, from small power of 16 tons to 68 tons of high-power horizontal directional drilling, XCMG series exporting quantities of drilling machinery Asia and Europe.
The specification as follow:
Items | Parameters | Unit | |
Engine | Make | Dongfeng Cummins |
|
Model | 6CTA8.3-C240 |
| |
Rated power | 179/2200 | kW/ rpm | |
Push/pull force | Type | 2-motor rack type |
|
Max. pull/push force | 400/400 | kN | |
Power head rotary speed | 0~22 | m/min | |
Slewing | Type | Motor drive gear transmission |
|
Max. torque of power head | 14000 | N.m | |
Power head rotary speed | 0~100 | r/min | |
Drill stem | Type | Standard API drill stem |
|
Diameter | φ83 | mm | |
Length (single) | 3 | m | |
Drill mounting | Type | Box type |
|
Adjustment angle | 10~22 | ° | |
Travel drive | Type | Self-propelled steel track |
|
Travel speed | 2.8 | km/h | |
Slurry pump | Type | Hydraulic drive |
|
Flow | 450 | L/min | |
Dimension |
| 7000x2170x2450 | mm |
Weight |
| 12 | t |
