2011-5-26
This day one unit SQ4ZK2 XCMG truck mounted knuckle crane as first trial order was dispatched to sea port. This kind of small crane can be delivery by LCL sea container. Save the freight cost and fast delivery
Specification as follow:
|
Model |
SQ4ZK2 |
Unit |
|
Max Lifting Moment |
8.4 |
t.m |
|
Max Lifting Capacity |
4000 |
kg |
|
Recommend Power Needed At Recommend Oil Flow |
14 |
kw |
|
Max Oil Flow of Hydraulic System |
25 |
l/min |
|
Rated Pressure Of Hydraulic System |
26 |
MPa |
|
Oil Tank Capacity |
60 |
L |
|
Rotation Angle |
370 |
。 |
|
Crane Weight |
1200 |
kg |
|
Installation Space |
850 |
mm |
|
SQ4ZK2 Lifting capability diagram |
||||
|
Working radius (m) |
2.1 |
4.15 |
5.8 |
7.3 |
|
Lifting capacity (kg) |
4000 |
1840 |
1260 |
920 |
