2013-7-19

Beibang machinery exported new truck crane QY70K-I this week. It innovative jib system adopts embedded block, plug-in boom head and international advanced U section jib, which has excellent lifting performance and safe and reliable lifting work.

Specification as follow:

Overall length: 13930mm

Overall width: 2800mm

Overall height: 3575mm

Total weight in travel: 43000(without 1t vice counterweight）kg

Front axle load: 17000kg

Rear axle load: 26000kg

Max. travel speed: 80km/h

Min. turning diameter: 24m

Min. ground clearance: 327mm

Max. rated total lifting capacity: 70t

Min. rated working radius: 3000m

Turning radius at turntable tail: 3.55m

Max. lifting torque: 2303kN.m

Base boom: 11.6m

Fully extended boom: 44.5m

Fully extended boom+ jib: 59.5m
