2010-12-22
This week we delivery one unit SQ10SK3Q Dongfeng 8*4 LHD driven hydraulic folding truck crane as Algeria customer requied.
Truck Crane is a cargo truck equipped with hydraulically powered articulated crane usually placed at the back of the cab or at the back of the truck. It is specifically designed for lifting (loading/unloading) the heavy goods for faster turnover.
|
Items |
Parameters |
|
Model of chassis |
EQ1208KB3GJ1 |
|
Total weight |
13000kg |
|
Load capacity |
7295kg |
|
Max speed |
90km/h |
|
Overall dimension |
11050×2480×3800mm |
|
Carriage dimension |
7450×2294×550mm |
|
Passengers |
3 |
|
Wheelbase |
5370+1300mm |
|
Distance of front and rear wheels |
1940/1860mm |
|
Drive mode/Number of shafts |
6*4/3 |
|
Approaching angle/Departure angle |
32/10 |
|
Front suspension/Rear suspension |
1245/3085 |
|
Number of steel plate springs |
8/12 |
|
Type of tire |
10.00-20 |
|
Model of engine |
B21033 |
|
Power of engine |
155/207 |
|
Engine output volume |
5900 |
|
Motor manufacture |
Dongfeng Cummins |
|
|
SQ10SK3Q |
|
Max lifting capacity |
10000 KG |
|
Max lifting capacity |
25 t.m |
|
Recommend power |
28 kw |
|
Max oil flow |
63 l/min |
|
Max pressure |
26 mpa |
|
Oil Tank Capacity |
180 l |
|
Crane weight |
3800 kg |
|
Installation space |
1150 mm |
|
Rotation angle |
all rotation |
|
Extension length |
9755 mm |
|
Lifting height |
13000 mm |
|
Max elevation |
75 degree |
