2012-12-18

Beibang machinery dispatched new Shantui SD32 bulldozer with single ripper this week. The bulldozer has the single ripper or 3 shank ripper for option.

Specification with SD32 as follow:

Dimension (Ripper not included): 6880×4130×3725mm

Operating weight (Ripper not included): 37.2t

Rated power: 235/2000kW/rpm

Blade type: Straight tilt blade-

Blade width: Straight tilt blade 4130×1590mm

Dozing capacity: Straight tilt blade 10m3

Ma× drop below ground of blade: 560mm

Lift height of blade: 1560mm

Ripper type: Single ripper

Ripping depth of ripper: Single ripper 1250mm

Lifting height of ripper: Single ripper 955Tmm

Number of carriers (each side): 2-

Number of track rollers (each side): 7

Number of track shoes (each side): 41

Width of track shoe: 560mm

Track gauge: 2140mm

Ground length and ground pressure: 3150-0.105 mm/MPa

Pitch: 228.6mm
