2015-4-23

Beibang machinery this month exported with shantui bulldozer SD23. This is hot model in Africa area.

The specification as

Dimension (Ripper not included): 5874×3725×3360mm

Operating weight (Ripper not included): 24.6t

Blade type: Straight tilt blade

Blade width: Straight tilt blade 3725×1395mm

Dozing capacity: Straight tilt blade 7.8m3

Ma× drop below ground of blade: 540mm

Lift height of blade: 1210mm

Ripper type: Single ripper, Three-shank ripper

Ripping depth of ripper: Single ripper 695,Three-shank ripper 666mm

Lifting height of ripper: Single ripper 515, Three-shank ripper 555mm

Number of carriers (each side): 2

Number of track rollers (each side): 7

Number of track shoes (each side): 39

Width of track shoe: 560/610/660mm

Track gauge: 2000mm

Ground length and ground pressure: 2840-0.078mm/MPa

Pitch: 216mm
