2015-8-18

This month beibang machinery new exported with Shantui budllzoer SD32W and SD23, SD32W rock bulldozer is specially designed for operation in tough working conditions with hard rock and frozen earth.

Dimension (Ripper not included): 6880×4130×2725mm

Operating weight (Ripper not included): 38t

Blade type: Straight tilt blade

Blade width: 4130×1590mm

Dozing capacity: 10m3

Ma× drop below ground of blade: 560mm

Lift height of blade: 1560mm

Ripper type: Single ripper

Ripping depth of ripper: Single ripper 1250mm

Lifting height of ripper: Single ripper 955mm

Number of carriers (each side): 2

Number of track rollers (each side): 7

Number of track shoes (each side): 41

Width of track shoe: 560mm

Track gauge: 2140mm

Ground length and ground pressure: 3150-0.105 mm/MPa

Pitch: 228.6mm
