XCMG Horizontal Directional Drills are mainly in the trenchless piping construction and replacement of the underground pipe. The XCMG Horizontal Directional Drills have the advantages of advanced performance, high efficiency and comfortable operation. Many key components adopt international famous products to guarantee the quality. They are the ideal machines for the construction of the water piping, gas piping, electricity, telecommunication, heating system, crude oil industry.
Model | Engine brand | Rade power (kW/ rpm) | Max.pullback/thrusting(kN) | Maximum torque(N.m) |
Cummins | 97 | 180/180 | 6000 | |
XZ200 | Dongfeng Cummins | 112/2200 | 200/200 | 6350 |
Dongfeng Cummins | 153/2000 | 320/320 | 12000 | |
Dongfeng Cummins | 154 / 2200 | 370/370 | 13200 | |
Dongfeng Cummins | 179/2000 | 400/400 | 14000 | |
Dongfeng Cummins | 179 / 2200 | 420/500 | 18500 | |
Dongfeng Cummins | 194/2200 | 450/450 | 17000 | |
Dongfeng Cummins | 194/2200 | 500 | 18000 | |
Dongfeng Cummins | 239/2200 | 725/725 | 28250 | |
Dongfeng Cummins | 264/2200 | 1000/10000 | 43000 /35000 | |
Cummins | 484 / 2100 | 1650 | 75000 | |
Cummins | 528 (2X264)/2200 | 2860/2860 | 90000 | |
Cummins | 528 / 2100 | 2860/2860(XZ2860) | 90000(XZ2860) / 110000(XZ2860Plus) | |
Chongqing Cummins | 2X298/2100 | 3000/300 | 110000 | |
Dongfeng Cummins | 132/2200 | 5000/5000 | 160000 | |
