Item | Unit | Specification |
Lifting performance | ||
Max. total rated lifting capacity | t | 85 |
Fixed jib Max. lifting capacity | t | 12 |
Luffing jib Max. lifting capacity | t | - |
Max. load moment | t.m | 341 |
Tower jib Max. lifting capacity | t | - |
Single block Max. lifting capacity | t | 8 |
Special jib Max. lifting capacity | t | - |
Dimensions | ||
Main boom length | m | 13~58 |
Main boom luffing angle | ° | -3~80° |
Fixed jib length | m | 7~19 |
Tower jib length | m | - |
Max. dimension of single unit(basic machine)in travel configuration(Lx W x H) | m | 13.05×3.4×3.3 |
Fixed jib installation angle | ° | 10°、30° |
Special jib length | m | - |
Working speed | ||
Winch Max. single line speed | m/min | 120 |
Boom luffing gear Max. single line speed | m/min | 70 |
Vice jib luffing gear Max. single line speed | m/min | - |
Max. slewing speed | r/min | 2 |
Max. travel speed | km/h | 0.9 |
Grade ability | % | 30% |
Mean ground pressure | MPa | 0.087 |
Tower jib luffing gear Max. single line speed | m/min | - |
Lifting device luffing gear Max. single line speed | m/min | - |
Power | ||
Engine model | SC9D272G2/QSC8.3 | |
Engine rated power | kW | 200/183 |
Discharge | NATIONII/EUR III | |
Weight | ||
Total weight | t | 71.5(main lifting hook,full counter weight,13m boom) |
Max. single unit weight for transportation | t | 41.2 |
