Main parameter

Operating weight :3 tons ,

Vibration frequency : 50 Hz,

Drum width:1200 mm,

Detailed configuration

Engine model ZN385Q,

Single drive, single vibratory drum .

Description	Unit	XMR353E
Operating weight	kg	3000
Roller diameter	mm	400
Roller width	mm	1200
Rolling system		Tandem type both drum drive
Power line		Hydraulic transmission
Final drive		Gear
Brake system		Hydraulic, mechanical pin lock
Speed	km/h	0-7.5
Gradeability	%	20
Centrifugal force	kN	30
Frequency	Hz	50
Engine model		ZN385Q
Rated speed	r/min	2400
Rated power	kw	28.5
Fuel tank capacity	L	65
Hydraulic tank capacity	L	40
Sprinkler capacity	L	180
Overall Dimensions(L/W/H)	mm	2690×756×1108
Transport Dimension(L/W/H)	mm	1337×756×1976
