Sales model		Unit	Specification(XE155D)
Operating weight		Kg	14600
Bucket capacity		m³	0.32-0.71
Engine	Model	/	QSF3.8
	Direct injection	/	√
	Four strokes	/	√
	Water cooling	/	√
	Turbo-charging	/	√
	No. of cylinders	/	4
	Output power	kw/rpm	93/2200
	Maximum torque/speed	N.m/rpm	500/1300
	Displacement	L	3.8
Main performance	Travel speed	km/h	5.3/3.2
	Swing speed	r/min	11.7
	Grade ability	°	35
	Ground pressure	kPa	37
	Bucket digging force	kN	106.9
	Arm digging force	kN	73.4
	Maximum traction	kN	134
Hydraulic system	Rated flow of main pump	L/min	123.5*2
	Main safety valve pressure	MPa	34.3/37
	Travel system pressure	MPa	34.4
	Rotary system pressure	MPa	25
	Pilot system pressure	MPa	3.9
Oil Capacity	Fuel tank capacity	L	260
	Hydraulic tank capacity	L	105
	Engine oil capacity	L	11
Appearance size	Overall length	mm	7795
	Overall width	mm	2590
	Overall height	mm	2900
	Width of platform	mm	2490
	Track length	mm	3658
	Overall width of chassis	mm	2590
	Track width	mm	600
	Length to center of rollers	mm	2910
	Track gauge	mm	1990
	Counterweight clearance	mm	948
	Min. ground clearance	mm	477
	Min. tail swing radius	mm	2325
	Track height	mm	836
Working scope	Max. digging height	mm	8649
	Max. dumping height	mm	6185
	Max. digging depth	mm	5535
	Maximum depth cut for 2240mm(8 ft) level bottom	mm	5324
	Max. vertical wall digging depth	mm	4697
	Max. digging radius	mm	8304
	Min. swing radius	mm	2445
Standard configuration	Length of boom	mm	4600
	Length of arm	mm	2520
	Bucket capacity	m³	0.61
Optional configuration	Length of boom	m³	/
	Length of arm	m³	2100/3010
	Bucket capacity	m³	0.32/0.4/0.71 Earth Working bucket
