Item | Unit | Specification |
Dimensions | ||
Overall length | mm | 13050 |
Overall width | mm | 2800 |
Overall height | mm | 3430 |
Weight | ||
Total weight in travel | Kg | 40400 |
Axle load | Kg | Front 14500/Rear 25900 |
Power | ||
Engine model | WD615.334 | |
Engine rated power | kw/(r/min) | 247/2200 |
Engine rated torque | N.m/(r/min) | 1350/1400 |
Travel | ||
Travelling | ||
Max. travel speed | km/h | 75 |
Min. stable travel speed | km/h | - |
Turning | ||
Min. turning diameter | m | 24 |
Max. grade ability | ％ | 46 |
Min. ground clearance | mm | 285 |
Approach angle | ° | 16 |
Departure angle | ° | 11 |
Fuel consumption for 100km | L | 46 |
Lifting performance | ||
Max. total rated lifting capacity | t | 40 |
Min. rated working radius | m | 3000 |
Base boom Max. load moment | kN·m | 1400 |
Turning radius at turntable tail | mm | 3482 |
Outrigger | ||
Longitudinal distance span | m | 5.65 |
Lateral distance span | m | 6.6 |
Max. lifting height | ||
Base boom | m | 10.7 |
Fully extended boom | m | 40.1 |
Fully extended boom＋jib | m | 55.1 |
Working speed | ||
Max. swing speed | r/min | ≥2.0 |
Lifting speed | ||
Boom full extension time | ||
extension | s | ≤180 |
Boom elevating time | ||
Lifting | s | ≤68 |
Dropping | s | - |
