Item | Unit | Specification |
Working performance | ||
Rated load | t | 9 |
Bucket capacity | m3 | 5 |
Dumping clearance | mm | 3400 |
Dumping reach | mm | 1400 |
Max. breakout force | kN | 260 |
Time for boom raising | s | 7 |
Total hydraulic cycle time | s | ≤13 |
Travelling performance | ||
Max. traction force | kN | - |
Min. turning radius (bucket edge) | mm | 6200 (To tire center) |
Max. travel speed | km/h | 35 |
Weight | ||
Operating weight | t | 30.04 |
Dimensions | ||
Overall dimensions(L×W×H) | mm | 9400×3500×3770 |
Wheel base | mm | 3600 |
Engine | ||
Engine model | Cummins QSM11 | |
Rated power/speed | kW/rpm | 250/2100 |
