Item | Unit | Specification |
Working performance | ||
Rated load | t | 4 |
Bucket capacity | m3 | 2.4 |
Dumping clearance | mm | 2841 |
Dumping reach | mm | 1100 |
Max. breakout force | kN | 130 |
Time for boom raising | s | 5.5 |
Total hydraulic cycle time | s | 10.5 |
Travelling performance | ||
Max. traction force | kN | 123 |
Min. turning radius (bucket edge) | mm | 6905 |
Max. travel speed | km/h | 35 |
Weight | ||
Operating weight | t | 14.2 |
Dimensions | ||
Overall dimensions(L×W×H) | mm | 7922×2800×3460 |
Wheel base | mm | 3100 |
Engine | ||
Engine model | SC8D170G2B1 | |
Rated power/speed | kW/rpm | 125/2200 |
