1. Optimized design of transport and assembly/ disassembly
Fully equipped self-assembly/disassembly system (Optional) can easily achieve: rear counterweight self-assembly/disassembly, track frame self-assembly/disassembly, and boom base self-assembly/disassembly.
Largest single unit transport weight is controlled within 30t, transport width not more than 3m, so as to meet the transport requirement of global accessibility.
Fixed jib can be three-piece integrated transport, and transport design of inserted boom sections, maximize the use of transport space, and save transport costs.
2. More optimized structural design
Superstructure is a large box-type structural design, with heavy load bearing capacity, light weight, and good rigidity.
Auxiliary hoisting winch is placed in boom base, with relaxed arrangement for turntable, easy maintenance.
Item | Unit | Specification |
Lifting performance | ||
Max. total rated lifting capacity | t | 100 |
Fixed jib Max. lifting capacity | t | 15.6 |
Luffing jib Max. lifting capacity | t | - |
Max. load moment | t.m | 580.3 |
Tower jib Max. lifting capacity | t | - |
Single block Max. lifting capacity | t | 12.5 |
Special jib Max. lifting capacity | t | - |
Dimensions | ||
Main boom length | m | 19～73 |
Main boom luffing angle | ° | 30～81 |
Fixed jib length | m | 13～25 |
Tower jib length | m | - |
Max. dimension of single unit(basic machine)in travel configuration(Lx W x H) | m | 10.5×3.0×3.25 |
Fixed jib installation angle | ° | 15、30 |
Special jib length | m | - |
Working speed | ||
Winch Max. single line speed | m/min | 110 |
Boom luffing gear Max. single line speed | m/min | 75.6 |
Vice jib luffing gear Max. single line speed | m/min | - |
Max. slewing speed | r/min | 1.8 |
Max. travel speed | km/h | 1.3 |
Grade ability | % | 0.3 |
Mean ground pressure | MPa | 0.087 |
Tower jib luffing gear Max. single line speed | m/min | - |
Lifting device luffing gear Max. single line speed | m/min | - |
Power | ||
Engine model | SC9DK270 | |
Engine rated power | kW | 200 |
Discharge | CHA III | |
Weight | ||
Total weight | t | 104.5 (main lifting hook,19m boom) |
Max. single unit weight for transportation | t | 30.9 |
